| Elektromagnetisk kompatibilitet | EN 55022 Class A; CISPR 22 Class A; VCCI V-3; FCC (CFR 47, Part 15) Subpart B Class A; VCCI V-4 |
| Immunitetsstandard | IEC 61000-4-2; IEC 61000-4-3; IEC 61000-4-4; IEC 61000-4-5; IEC 61000-4-6; IEC 61000-4-8; IEC 61000-4-11; EN 61000-3-2; EN 61000-3-3 |
| Samsvar med industristandarder | EN: EN 55024, CISPR 24; ESD: IEC 61000-4-2; Radiated: IEC 61000-4-3; EFT/Burst: IEC 61000-4-4; Surge: IEC 61000-4-5; Conducted: IEC 61000-4-6; Power frequency magnetic field: IEC 61000-4-8; Voltage dips and interruptions: IEC 61000-4-11; Harmonics: IEC 61000-3-2; Flicker: IEC 61000-3-3 |
| Sikkerhet | CSA 22.2 No. 60950; EN 60950/IEC 60950; UL 60950 |
| Akustisk trykkemisjon | Power: 0 dB, no fan |
| Driftshøyde | up to 3 km |
| Luftfuktighetsområde ved drift | 15 to 95% @ 104°F (40°C) (noncondensing) |
| Fuktighet ved lagring | 15 to 90% @ 149°F (65°C) (noncondensing) |
| Lagringstemperatur | -40 to 70°C |
| Driftstemperaturområde | 0 to 40°C |
| Varmespredning | 51 BTU/hr (53.81 kJ/hr) |
| Størrelse på adressetabell | 8000 entries |
| Administrasjonsfunksjoner | Web browser |
| Kommunikasjon | CPU DoS Protection; IEEE 802.1p Priority; IEEE 802.1Q VLANs; IEEE 802.3ad Link Aggregation Control Protocol (LACP); IEEE 802.3x Flow Control; RFC 1534 DHCP/BOOTP Interoperation; RFC 2030 Simple Network Time Protocol (SNTP) v4 |
| Nekting av tjeneste-beskyttelse | CPU DoS Protection |
| Generelle protokoller | IEEE 802.1p Priority; IEEE 802.1Q VLANs; IEEE 802.3ad Link Aggregation (LAG); IEEE 802.3x Flow Control; RFC 1534 DHCP/BOOTP Interoperation; RFC 2030 Simple Network Time Protocol (SNTP) v4 |
| Nettverksadministrasjon | IEEE 802.1AB Link Layer Discovery Protocol (LLDP) |
| Latens | 100 Mb Latency: < 3.9 µs (64-byte packets); 1000 Mb Latency: < 2.1 µs (64-byte packets) |
| Gjennomløp | up to 11.9 million pps (64-byte packets) |
| Svitsjekapasitet | 16 Gbps |
| Porter | 8 RJ-45 autosensing 10/100/1000 ports(IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T), Duplex: 10BASE-T/100BASE-TX: half or full; 1000BASE-T: full only; Supports a maximum of 8 autosensing 10/100/1000 ports |
| Bilde, juridisk ansvarsfraskrivelse | Product image may differ from actual product |
| Minimumsmål (B x D x H) | 19.63 x 11.63 x 4.39 cm |
| Vekt | 0.54 kg |
| Tekniske merknader | Power: external AC power adapter and IEEE 802.3af-compatible PoE-PD, class 3 on Port 1 |
| Garanti | Lifetime, advance replacement, next business day |
| Minne og prosessor | 8 MB flash, packet buffer size: 512 KB, 16 MB SDRAM |
| Strømtilgjengelighet | 0.5 A |
| Strøm | The exact input voltage and frequency rating are determined by the specific power adapter part number ordered. Please select the correct power adapter country option. |
| Strømforbruk | 15 W (maximum) |
| Nettfrekvens | 50/60 Hz |
| Driftsstrøm inn | 0.5 A |
| Strøm | 100 -240 VAC; 50 /60 Hz |
| Nettspenning | 100-240 VAC |
| Montering | Wall, ceiling, desktop, and under-table mounting |
| Rack-montering | Wall, ceiling, desktop, and undertable mounting |
| Formfaktor | 1U height |
