| Key Points |
|
|
|
| Unique Features |
|
|
|
| Optical |
|
|
|
| Display Technology |
|
0.55" DLP by Texas Instruments with BrilliantColor |
|
| Resolution |
|
|
|
| Native |
|
XGA 1024 x 768 |
|
| Maximum |
|
UXGA 1600 x 1200 |
|
| Light Output (lumens) |
|
2500 normal |
|
| Contrast Ratio |
|
2000:1 |
|
| Lamp Type |
|
180W AC |
|
| Lamp Life (up to) |
|
3500 hours normal / 5000 hours eco |
|
| Screen Size (diagonal) |
|
33 to 300 in. / 838 to 7620mm |
|
| Throw Ratio |
|
1.95 to 2.15 |
|
| Projection Distance |
|
3.9 to 39.4 ft. / 1.2 to 12m |
|
| Projector Angle |
|
14º wide / 12.7º tele |
|
| Lens |
|
|
|
| Zoom |
|
1 - 1.1 |
|
| Focus |
|
Manual |
|
| F-number, f-number |
|
F=2.41 to 2.55, f=21.83 to 24mm |
|
| Shift |
|
|
|
| Keystone Correction |
|
+/- 40 degrees |
|
| Signal Compatibility/Connectivity |
|
|
|
| Scan Rate |
|
|
|
| Horizontal |
|
15 - 100 kHz / |
|
| Vertical |
|
50 - 120 Hz |
|
| Supported Video Standards |
|
NTSC, NTSC4.43, PAL-M, N, B, D, G H, I, SECAM |
|
| SD/HD Video Signal Compatibility |
|
480i, 576i, 480p, 576p, 720p, 1080i |
|
| PC Signal Compatibility |
|
VGA, SVGA, XGA, WXGA, WXGA+, SXGA, SXGA+, UXGA |
|
| Macintosh Compatibility |
|
Yes |
|
| Input/Output Terminals |
|
|
|
| RGB 1 (analog) |
|
15-pin, component video using 15-pin adapter |
|
| RGB 2 (analog) |
|
15-pin |
|
| RGB 3 (digital) |
|
|
|
| Video 1 |
|
S-Video |
|
| Video 2 |
|
RCA |
|
| Video 3 |
|
|
|
| HD Video 1 |
|
|
|
| HD Video 2 |
|
|
|
| Audio |
|
Mini stereo |
|
| Monitor out |
|
Yes |
|
| Audio out |
|
|
|
| Audio |
|
7W speaker |
|
| External Control |
|
RS-232, IR, Wired LAN (NP215 only) |
|
| Sync Compatiblity |
|
Separate Sync / Composite Sync / Sync on G |
|
| Networking |
|
|
|
| Electrical |
|
|
|
| Power Req. |
|
100 - 240V AC, 50/60 Hz |
|
| Input Current |
|
2.6A |
|
| Power Consumption |
|
242W / 217W / 4W / 0.49W |
|
| Mechanical |
|
|
|
| Installation Orientation |
|
Table/Front, Table/Rear, Ceiling/Front, Ceiling/Rear |
|
| Dimensions (WxDxH) |
|
12.2 x 3.7 x 9.7 in. / 310 x 95 x 247mm |
|
| Net Weight |
|
5.7 lbs. / 2.6 kg |
|
| Fan Noise |
|
34 dB |
|
| Regulations |
|
USA UL 1950 FCC Class B, Canada CSA 950 (C-UL), NOM |
|
| Environmental |
|
|
|
| Operational Temp. |
|
41º - 104ºF / 5º - 40ºC |
|
| Humidity |
|
20-80% non-condensing |
|
| Storage |
|
-4º - 122ºF / -20º - 50ºC |
|
| Warranty |
|
2 years |
|
| Additional Features |
|
|
|
| SquareShot™ |
|
|
|
| VORTEX™ Technology Plus |
|
|
|
| Autosense™ |
|
AutoSense™ automatically syncs with any computer signal and features one-touch image optimization |
|
| SweetVision II™ |
|
|
|
| 3D Reform™ |
|
|
|
| Automatic keystone correction |
|
|
|
| Built-in Wall Color Correction |
|
Built-in wall color correction presets provide for adaptive color tone correction to display properly on non-white surfaces |
|
| Advanced AccuBlend™ |
|
|
|
| Kensington Lock Slot |
|
Enables security cable to be attached to projector. |
|
| Image Magnification |
|
64-step image magnification with location control |
|
| Sleep Timer |
|
Countdown sleep timer can be set to automatically turn off the projector |
|
| Eco-Mode™ Technology |
|
Extended lamp life with ECO Mode™ technology increases lamp life up to 5000 hours, while lowering power consumption |
|
| Discreet Source Keys |
|
Discreet source keys for source selection |
|
| Computer free presentations |
|
|
|
| High speed wireless |
|
|
|
| Direct Power Off |
|
|
|
| In the Box |
|
Remote control, batteries, RGB cable, power cord, user's manual, product registration card |
|
