| Elektromagnetisk kompatibilitet | FCC Rules Part 15, Subpart B Class A; EN 55022; VCCI; ICES-003 (Canada) |
| Immunitetsstandard | EN 55024, CISPR 24; IEC 61000-4-2; IEC 61000-4-3; IEC 61000-4-4; IEC 61000-4-5; IEC 61000-4-6; IEC 61000-4-8; IEC 61000-4-11; IEC 61000-3-2; IEC 61000-3-3 |
| Samsvar med industristandarder | EN55024, CISPR 24; ESD: IEC 61000-4-2; Radiated: IEC 61000-4-3; EFT/Burst: IEC 61000-4-4; Surge: IEC 61000-4-5; Conducted: IEC 61000-4-6; Power frequency magnetic field: IEC 61000-4-8; Voltage dips and interruptions: IEC 61000-4-11; Harmonics: IEC61000-3-2; Flicker: IEC61000-3-3 |
| Sikkerhet | CSA 22.2 No. 60950; EN 60950/IEC 60950; UL 60950 |
| Akustisk trykkemisjon | Power: 0 dB, No Fan |
| Driftshøyde | up to 3 km |
| Luftfuktighetsområde ved drift | 15 to 95% @ 104°F (40°C) (noncondensing) |
| Fuktighet ved lagring | 10 to 90% @ 149°F (65°C) (noncondensing) |
| Driftstemperaturområde | 0 to 40°C |
| Lagringstemperatur | -40 to 70°C |
| Varmespredning | 61 BTU/hr (64 kJ/hr) |
| Størrelse på adressetabell | 8000 entries |
| Administrasjonsfunksjoner | Web browser |
| Kommunikasjon | General Protocols: IEEE 802.1p Priority; IEEE 802.1Q VLANs; IEEE 802.3ad Link Aggregation; Control Protocol (LACP); IEEE 802.3x Flow Control; Network Management: IEEE 802.1AB Link Layer; Discovery Protocol (LLDP) |
| Generelle protokoller | IEEE 802.1p Priority; IEEE 802.1Q VLANs; IEEE 802.3ad Link Aggregation Control Protocol (LACP); IEEE 802.3x Flow Control; RFC 1534 DHCP/BOOTP Interoperation |
| Nettverksadministrasjon | IEEE 802.1AB Link Layer Discovery Protocol (LLDP) |
| Latens | 100 Mb Latency: < 3.9 µs (64-byte packets); 1000 Mb Latency: < 2.1 µs (64-byte packets) |
| Gjennomløp | up to 2.0 million pps (64-byte packets) |
| Svitsjekapasitet | 3.4 Gbps |
| Porter | 7 autosensing 10/100 ports(IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX), Media Type: Auto-MDIX, Duplex: half or full; 1 autosensing 10/100/1000 port(IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T), Media Type: Auto-MDIX, Duplex: 10BASE-T/100BASE-TX: half or full; 1000BASE-T: full only |
| Bilde, juridisk ansvarsfraskrivelse | Product image may differ from actual product |
| Webadresse for tilleggsinformasjon | http://www.hp.com/go/procurve/ |
| Minimumsmål (B x D x H) | 11.63 x 19.63 x 4.39 cm |
| Vekt | 0.54 kg |
| Garanti | Lifetime, advance replacement, next business day |
| Minne og prosessor | 1 MB flash, packet buffer size: 144 KB, 1 MB RAM/ROM capacity |
| Strømtilgjengelighet | 1.0 A/0.8 A |
| Strøm | The exact input voltage and frequency rating are determined by the specific power adapter part number ordered. Please select the correct power adapter country option. |
| Strømforbruk | 18 W (maximum) |
| Nettfrekvens | 50/60 Hz |
| Driftsstrøm inn | 1.0/0.8 A |
| Strøm | 100-127 VAC/200-240 VAC; 50/60 Hz |
| Nettspenning | 100-127/200-240 VAC |
| Montering | Horizontal surface mounting only |
| Rack-montering | Horizontal surface mounting only |
| Formfaktor | 1U height |
