| PRODUCT NAME |
Epson EB-475W |
| PRODUCT CODE |
V11H455053 |
| WHAT'S IN THE BOX |
| |
Projector including 5m Power Cable, Remote Control, Batteries x 2, Projector Software Ver. 1.03b (CD ROM), Password Protect Sticker, User Manual Set, Setting Plate (mount), Template Sheet. |
| TECHNOLOGY |
| Projection System |
Epson 3LCD, 3-chip technology |
| LCD Panel |
0.59-inch with MLA |
| OPTICAL |
| Zoom |
1 - 1.35 (Optical Zoom) |
| Screen Size |
60" to 102" |
| Projection Distance |
74.3" screen 0.438m |
| Throw Ratio |
0.27 (Zoom: Wide), 0.37 (Zoom: Tele) |
| Projection Lens F Number |
1.80 |
| Projection Lens Focal Length |
3.71mm |
| Focus Method |
Manual Focus |
| Offset |
6.0:-1 |
| IMAGE |
| Colour Light Output |
2,600 Lumens |
| White Light Output |
2,600 Lumens |
| Resolution |
WXGA |
| Native Aspect Ratio |
16:10 |
| Contrast Ratio |
3,000:1 |
| Lamp Hours |
Normal/Eco: 3,000/4,000 Hours |
| Lamp Type |
190W UHE |
| Keystone Correction |
Vertical: -5 to +5 degrees Horizontal: -5 to +5 degrees |
| CONNECTIVITY |
| Input: Video |
1 x RCA (Yellow), 1 x S-Video, 2 x Component (via D-sub 15-pin) |
| Input: Computer |
2 x D-sub 15-Pin (RGB), 1 x USB 2.0 type B |
| Input: USB Memory Device |
USB Type A Ver.2.0 |
| Input: Three-In-One USB Display |
1 x USB 2.0 type B |
| Input: Digital |
1 x HDMI |
| Input: Audio |
1 x RCA (Red/White), 2 x Stereo mini jack |
| Input: Control |
1 x USB 2.0 type B, RS232C |
| Input: Epson USB Document Camera |
1 x USB 2.0 type B |
| Network I/O: |
RJ45 x 1 (100Mbps) |
| Wireless Connectivity |
Optional |
| Output: Video |
D-sub 15 pin (monitor out black moulding) |
| Output: Audio |
Stereo mini jack x 1 |
| Speaker Output |
16W |
| ADVANCED FEATURES |
| EasyMP Network & Control |
Yes |
| EasyMP Network Projection |
Yes |
| PC Free Presentations |
No |
| USB Plug 'n Play |
Yes |
| AV Mute Slide |
No |
| Instant Off |
Yes |
| Direct Power On/Off |
Yes |
| Security |
Kensington®-style lock provision Padlock & Security cable hole Wireless LAN unit lock Password protect function |
| Colour Modes |
Dynamic, Theatre |
| GENERAL |
| Dimensions D x W x H |
375 x 367 x 143mm |
| Weight |
5.4kg |
| Lamp Warranty |
12 months or 750 hours* |
| Projector Warranty |
3 Years |
| Power Consumption: Lamp on |
Normal: 275W / Eco: 215W |
| Power Consumption: Standby |
0.27W (communication off) |
| Noise Level |
Normal: 35dB / Eco: 28dB |
|
| * Whichever comes first. |
| PRODUCT OPTIONS |
| |
V13H010L71
|
Lamp |
| |
V12H003B29 |
Table Mount to suit EB-470/475W/475Wi/480/485W/485Wi |
| |
V13H134A40 |
Air-Filter |
| |
V12H418P13 |
Wireless LAN Adapter to suit EB-470/475W/475Wi/480/485W/485Wi |
| |
V12H005M08 |
Quick Wireless Key to suit EB-470/475W/475Wi/480/485W/485Wi |
| |
V12H522001 |
Interactive Pen ELPPN03A (orange) for EB-475Wi, EB-475Wie and EB-485Wi |
| |
V12H523001 |
Interactive Pen ELPPN03B (blue) for EB-475Wi, EB-475Wie and EB-485Wi |
| |
5YWEB485W |
Additional 2 year warranty (upgrade to 5 years) |
| |
|
|
